Acea Biosciences NovoCyte 2000 Flow Cytometer

Description

Address the full range of current and future multi-parameter cellular analysis research needs with the NovoCyte flow ​cytometer. ACEA brings researchers high performance flow cytometry at a low investment cost with the NovoCyte platform. Lasers: Blue 488 nm, Red 640 nm Detectors: 530, 585, 675 nm Laser Configuration: Spatially separated beams with 10 x 80 μm elliptical spots Optical Alignment Procedure: Fixed, no operator alignment required Flow Cell: 170 x 290 μm rectangular quartz flow cell FSC/SSC Resolution: FSC < 0.5 μm, SSC < 0.2 μm Cell Size: 0.2 – 50 μm Fluorescence Threshold Sensitivity: FITC < 75 MESF, PE < 50 MESF Fluorescence Resolution: < 3% CV for CEN Filters: User Exchangeable Sample Acquisition Rate: 35,000 events/second Volumetric Absolute Count Precision: CV < 5% Sample Flow Rate: 5 – 120 μL/min Sheath Flow Rate: 6.5 mL/min Sample Aspiration Volume: 10 – 100 μL Fluid Container Capacity: 3 L sheath, 3 L waste, 500 mL cleaning, 500 mL decontamination Carryover: < 0.1% Fluidics Maintenance: Automated startup, cleaning, decontamination and shutdown Manual Sample Loading: 12 x 75 mm tube Dimension (WxDxH): 600 x 450 x 390 mm Weight: 39 k
