Description
Almatec E10UTT Diaphragm Pump The Almatec E10UTT is a compact, air-driven double diaphragm pump (AODD) from the high-performance E-Series. The pump is designed for the safe pumping of aggressive, corrosive, and chemical liquids. The plastic PTFE version is suitable for demanding chemical applications and is available in ATEX versions. The pump is self-priming and operates entirely pneumatically, meaning no electric drive is required on the liquid side. Technical specifications Specification Data Brand Almatec Type E10UTT Series E-Series Pump type Pneumatic double diaphragm pump (AODD) Material Plastic / PTFE Housing PTFE conductive Diaphragms PTFE/EPDM compound Ball valves PTFE Nominal fluid connection 3/8″ NPT Air connection R 1/8″ BSP Maximum capacity 23 l/min (1.4 m³/h) Maximum operating/compressed air pressure 7 bar (100 psi) Maximum operating temperature 100 °C Maximum particle size 3 mm Self-priming, dry up to approx. 2 m* Self-priming, wet up to approx. 9 m ATEX Suitable for ATEX version, depending on exact configuration Weight approx. 5 kg Dimensions L × W × H 110 × 147 × 169 mm
Pre-owned equipment sold by a third-party reseller through MerkaLoop. Ships directly from the reseller.
Specifications
- Condition
- Good
- Manufacturer
- Almatec
- Model
- E10UTT Diaphragm Pump
- Equipment weight
- 5 kg
- Equipment dimensions
- 11 × 17 × 15 cm
Shipping & Logistics
MerkaLoop coordinates all logistics. Timelines depend on seller location and your destination.
- MerkaLoop coordinates all logistics
- Shipping quoted before payment
- Ships globally
Shipping from: Netherlands
