Applikon Bio Sep ADI 1015 Controller Unit
Applikon · Bio Sep ADI 1015 Controller Unit · ref ML-A8B2906E
Description
The ADI 1015 controller consists of a frequency generator and a power amplifier as well as an automatic frequency control (AFC) system to track the resonance frequency and an adjustable timer to specify the run/stop cycle times for the harvest pump and resonator. Power supply: 110-120/220-240 VAC, 50/60 Hz Power consumption: 90 W Frequency range: 2.1 – 2.15 MHz Output power: 15 W max. Output voltage: 25 Vp max. Internal Timer: Run time: 10 – 600 s Stop time: 1 – 60 s DC source (100 mA max.): Pin 1: +5V Pin 2: 0V reference (isolated from system ground) Pin 3: -5V Interrupt output (24 VDC/100 mA max. switching load): Pin 4/5 closed: RF on Pin 5/6 closed: RF off Status output (24 VDC/100 mA max. switching load): Pin 7/8 closed: O.K. Pin 8/9 closed: alarm External stop input: Pin 10/11: apply 3-15 VDC (2-30 mA) to cause an interrupt Case ground: Pin 12 Dimensions (H x W x D): 140 x 240 x 295 mm Weight: 5.5 kg
Pre-owned equipment sold by a third-party reseller through MerkaLoop. Ships directly from the reseller.
Specifications
- Condition
- Good
- Manufacturer
- Applikon
- Model
- Bio Sep ADI 1015 Controller Unit
- Pin 1
- +5V
- Pin 2
- 0V reference
- Pin 3
- -5V
- Warranty
- 1 month
- Pin 10 11
- apply 3-15 VDCto cause an interrupt
- Stop Time
- 1 – 60 s
- Case Ground
- Pin 12
- Output Power
- 15 W max.
- Power Supply
- 110-120/220-240 VAC, 50/60 Hz
- Internal Timer
- Run time: 10 – 600 s
- Output Voltage
- 25 Vp max.
- Pin 4 5 Closed
- RF on
- Pin 5 6 Closed
- RF off
- Pin 7 8 Closed
- O.K.
- Pin 8 9 Closed
- alarm
- Frequency Range
- 2.1 – 2.15 MHz
- Power Consumption
- 90 W
- Dimensions H X W X D
- 140 x 240 x 295 mm
Shipping & Logistics
MerkaLoop coordinates all logistics. Timelines depend on seller location and your destination.
- MerkaLoop coordinates all logistics
- Shipping quoted before payment
- Ships globally
Shipping from: Netherlands
It is your responsibility to check local regulations and requirements for the handling, acceptance, and servicing of secondhand and new equipment.
