Leica RM2235 Microtome
Leica · RM2235 Microtome · 2011 · ref ML-B584198F
Description
The Leica RM2235 rotary microtome is equipped with a low maintenance, slack-free micrometer drive, with vertical and horizontal specimen feed realized via low-maintenance cross roller bearings. The instrument is equipped with two independent handwheel locking systems for even greater operating safety. Leica’s patented, user-adjustable force balance system compensates centrifugal forces arising while cutting via a pretensioned spring for extremely light handwheel action. Section thickness range: 1.0 – 60.0 μm Section thickness settings: from 1.0 – 10.0 μm in 1.0 μm increments, from 10.0 – 20.0 μm in 2.0 μm increments, from 20.0 – 60.0 μm in 5.0 μm increments Specimen feed: approx. 24 mm, ± 2 mm Vertical stroke: 70 mm Max. sectioning range without retraction: 69 mm (without specimen orientation at 1 μm) Max. sectioning range with retraction: 62 mm The specimen retraction can be turned off manually: 200 μm Dimensions (WxDxH): 413 x 618 x 305 mm Working height (knife blade): 168 mm (measured from the table) Weight: 37 kg
Pre-owned equipment sold by a third-party reseller through MerkaLoop. Ships directly from the reseller.
Specifications
- Condition
- Good
- Year Manufactured
- 2011
- Manufacturer
- Leica
- Model
- RM2235 Microtome
- Warranty
- 6 months
- Specimen Feed
- approx. 24 mm, ± 2 mm
- Vertical Stroke
- 70 mm
- Dimensions Wxdxh
- 413 x 618 x 305 mm
- Section Thickness Range
- 1.0 – 60.0 μm
- Section Thickness Settings
- from 1.0 – 10.0 μm in 1.0 μm increments, from 10.0 – 20.0 μm in 2.0 μm increments, from 20.0 – 60.0 μm in 5.0 μm increments
- Working Height Knife Blade
- 168 mm
- The Specimen Retraction Can Be Turned Off Manually
- 200 μm
