Bio-Rad Bio-Plex Array System
Bio-Rad · Rad Bio-Plex Array System · ref ML-C5EEA448
Description
The Bio-Plex system is a suspension array system which offers protein and nucleic acid researchers a reliable multiplex assay solution that permits analysis of up to 100 biomolecules in a single sample. Reporter laser: 532 nm, >10 mW, frequency-doubled diode; 30 x 60 µm elliptical beam Classification laser: 635 nm, 10 mW, diode; 30 x 60 µm elliptical beam Sheath flow rate: 90 µl/sec Cuvette: 200 µm square flow channel Sample injection rate: 60 µl/sec Reporter channel detection: Photomultiplier tube, A/D resolution 14 bits Classification and doublet discriminator channel detection: Avalanche photodiodes with temperature compensation, A/D resolution 12 bits Measurement resolution: 15 bits effective Processor modes: Linear, with logarithmic or linear display option Dynamic range: 70 dB Plate capacity: One 96-well microtiter plate, ≤0.75 Dimensions (W x D x H): 440 x 610 x 310 mm Weight: 37.4
Pre-owned equipment sold by a third-party reseller through MerkaLoop. Ships directly from the reseller.
Specifications
- Condition
- Good
- Manufacturer
- Bio-Rad
- Model
- Rad Bio-Plex Array System
- Cuvette
- 200 µm square flow channel
- Warranty
- 6 months
- Dynamic Range
- 70 dB
- Plate Capacity
- One 96-well microtiter plate, ≤0.75
- Reporter Laser
- 532 nm, >10 mW, frequency-doubled diode; 30 x 60 µm elliptical beam
- Processor Modes
- Linear, with logarithmic or linear display option
- Sheath Flow Rate
- 90 µl/sec
- Classification Laser
- 635 nm, 10 mW, diode; 30 x 60 µm elliptical beam
- Dimensions W X D X H
- 440 x 610 x 310 mm
- Sample Injection Rate
- 60 µl/sec
- Measurement Resolution
- 15 bits effective
- Reporter Channel Detection
- Photomultiplier tube, A/D resolution 14 bits
- Classification And Doublet Discriminator Channel Detection
- Avalanche photodiodes with temperature compensation, A/D resolution 12 bits
Shipping & Logistics
MerkaLoop coordinates all logistics. Timelines depend on seller location and your destination.
- MerkaLoop coordinates all logistics
- Shipping quoted before payment
- Ships globally
Shipping from: Netherlands
It is your responsibility to check local regulations and requirements for the handling, acceptance, and servicing of secondhand and new equipment.
contact MerkaLoop about this equipment
