Biotage Isolera Four Flash Chromatography System

Specifications

Condition

Good

Manufacturer

Biotage

Model

Isolera Four

Max Pressure

0 to 10 bar bar

Power

Input Voltage 100-240 VAC, 50/60 Hz; Fuses 4.0 TA/250 V, P/N 411916; Max Power Consumed 200 VA

Display

10.4" LCD; TFT active matrix; 800 x 600 resolution; solvent stable touch screen

Solvents

4 x 4-liternon-glass reservoirs on the solvent tray; up to 2.5-liter glass reservoirs

Interfaces

LAN port, two USB ports, mouse port, VGA port, external detector port, and leak detector port

Rack Types

13x100 mm, 16x100 mm, 18x130 mm, 16x150 mm, 18x150 mm, 25x150 mm, 120 ml, 240 ml, 480 ml

Certification

CE, UL, CAN/CSA; EN 61010-1: 2001, EN 1127-1:2007, EN 61326-1:2006, CAN/CSA-C22.2 No. 61010-1-04, UL 61010-1:2004

Flow Rate Range

1 to 200 ml/min, in 1 ml/min increments

Fraction Volume

Programmable from 1 to 9999 ml, depending on rack type

Max Total Volume

4800 ml with no rack change, 480 ml bottle racks

Gradient Precision

±2%

Cartridge Positions

4

Max Fraction Number

192 fractions with no rack change, 13x100 mm racks

Instrument Weight Kg

30-35 kgdepending on system configuration

Operating Conditions

Location: A laboratory fume hood with capacity to handle leakage of solvents. Temperature 15°C to 32°C. Humidity 20% to 95% at room temperature.

Instrument Dimensions

Width: 355 mmor, when using a system with two collection trays, 577 mm; Height: 596 mm; Depth: 497 mm

Software Compatibility

On-board Isolera software; lambda-all and TLC to Step Gradient editor need a Spektra licence. No external PC required.

Internal Detector Wavelength

200 nm to 400 nm, 200 to 800 nm, or 254 nm. Amplitude Range 0 to 6 AU; accuracy of ± 0.04 AU. Flow Cell Optical Path 0.3 mm. UV lamp Deuterium discharge, 25 W; Tungsten lamp 10 W

Technique

Flash
