Beckman Coulter Echo 655 Acoustic Liquid Handler (with Workstation)
Beckman Coulter · Echo 655 · 2021 · ref ML-D1AFEBE8
30-day seller warranty from delivery on hardware function; excludes consumables, installation, calibration and software licensing.
Description
About this model
The Echo 655 is an acoustic liquid handler from the Echo 650 Series (originally Labcyte, now Beckman Coulter Life Sciences). It transfers liquid by acoustic droplet ejection, without tips, pins or nozzles, in 2.5 nL droplets from 384-well and 1536-well Echo Qualified source plates to 96, 384, 1536 and 3456-well destination plates. Typical uses are compound management, dose-response and combination screening, assay miniaturisation and genomics set-up.
This unit
Beckman Coulter Echo 655 acoustic liquid handler from 2021, the high-throughput model of the Echo 650 Series, with its control workstation. Condition and testing: used. The photographs show the instrument powered on with the status display reading ready and the Echo software open on the workstation. Software and computer: workstation PC with monitor, keyboard and mouse, with Echo software installed.
What's Included
Echo 655 instrument, workstation PC, monitor, keyboard, mouse, Echo software as installed.
Pre-owned equipment sold by a third-party reseller through MerkaLoop. Ships directly from the reseller.
Specifications
- Condition
- Good
- Year Manufactured
- 2021
- Manufacturer
- Beckman Coulter
- Model
- Echo 655
- Vacuum
- House vacuum minimum 200 Torr at 2.0 m3/h, or standalone vacuum pump with surge tank
- Software
- Echo Software Applications v1.7 or higher; ActiveX integration interface
- Client Pc
- Windows 7or Windows 10 64-bit client PC with Ethernet
- Technology
- Acoustic droplet ejection
- Dimensions Mm
- 538 W x 746 D x 915 H
- Volume Max Nl
- 5000
- Volume Min Nl
- 2.5
- Compressed Air
- Filtered, oil-free, dry air, 5.52 to 10.34 bar, minimum 1 cfm
- Coupling Fluid
- Type 1 ultra-pure water, held at 22.1 C +/- 0.9 C by an external recirculating chiller
- Drop Volume Nl
- 2.5
- Working Envelope
- 25.4 cm above, 2.5 cm each side, 15.2 cm front, 30.5 cm rear
- Transfer Accuracy
- <10% deviation from target volume
- Transfer Precision
- <8% CV
- Destination Labware
- Echo Qualified microplates, 96-tube racks and most ANSI/SBS microplates in 96, 384, 1536 and 3456-well formats
- Operating Temperature
- 21 C +/- 5 C
- Dmso Hydration Accuracy
- <8% deviation from target
- Dmso Hydration Precision
- <5% CV
Shipping & Logistics
MerkaLoop coordinates all logistics. Timelines depend on seller location and your destination.
- MerkaLoop coordinates all logistics
- Shipping quoted before payment
- Ships globally
Shipping from: United States
It is your responsibility to check local regulations and requirements for the handling, acceptance, and servicing of secondhand and new equipment.
